Description
FEATURES
| WiFi Connect | Built-In |
| Filler trim kit | JXTR32B |
| Cooktop Burner Type | 5 Ribbon Smoothtop |
| Melt Setting | Yes |
| Fuel Type | Electric |
| Element – Left Front | 7″ 1500W |
| Indicator Lights | 5 Hot Surface Red Surface Element “ON” |
| Element – Right Front | 8″/5″ 2200W Dual |
| Control Location | Front Center |
| Cooktop Type | Radiant Smoothtop |
| Cooktop Surface | |
| Cooktop Control Features | All-Off Control Control Lock Capability Custom Settings Keep-Warm Setting Kitchen timer LED Light level adjustment Melt Setting Sound adjustment Sync-Burners Capability |
| WiFi Enabled Features | Bluetooth Pairing – Chef Connect with Hoods/OTRs and HestenCue Pans (HMI) Guided cooking with HestanCue Pans (App) Interfaces with SmartHQ App Precision cooking with HestanCue Pans (HMI and App) |
| Element – Left Rear | 7″ 1500W (Keep Warm) |
| Control Type | Electronic Glide Touch |
| Element – Center | 9″/7″/5″ 3000W Tri-ring Power Boil |
| Element – Right Rear | 6″ 1200W (Melt) |
| Product Type | Cooktop |
APPEARANCE
| Frame Color / Material | Stainless Steel |
| Color Appearance | Stainless Steel |
WEIGHTS & DIMENSIONS
| Cooktop Size | 30.00 |
| Overall Height | 3 3/8 |
| Cabinet Width | 30.00 |
| Approximate Shipping Weight | 40.00 |
| Cutout Dimensions (Width x Depth) (In.) | 28.00 |
| Overall Width | 29 7/8 |
| Net Weight | 34.00 |
| Overall Depth | 21 1/2 |
POWER / RATINGS
| Recommended Circuit Breaker (Amps) at 240V | 40 |
| Max. Connected Load (kW) at 240V | 9.5 |
| Max. Current Draw (Amps) at 240V | 39.6 |
| Max. Connected Load (kW) at 208V | 7.1 |
| Recommended Circuit Breaker (Amps) at 208V | 40 |
| Max. Current Draw (Amps) at 208V | 34.1 |
ACCESSORIES
| Griddle Accessory | JXGRIDL1 (optional) |
WARRANTY
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| Labor Warranty | Limited 1-year entire appliance |
CERTIFICATIONS
| Claims & Certifications | ADA Compliant UL California Prop 65 |
