Description
FEATURES
| Filler trim kit | JXTR32B (not included) |
| Cooktop Burner Type | 5 Ribbon Smoothtop |
| Melt Setting | Yes |
| Fuel Type | Electric |
| Element – Left Front | 7″ 1500W (Keep Warm) |
| Indicator Lights | 5 Hot Surface Red Surface Element “ON” |
| Element – Right Front | 8″/5″ 2400W Power Boil |
| Control Location | Front Center |
| Cooktop Type | Radiant Smoothtop |
| Cooktop Surface | |
| Cooktop Control Features | Keep-Warm Setting Melt Setting |
| Timer | Yes |
| Element – Left Rear | 6″ 1200W |
| Control Type | Knob (Infinite switch) |
| Element – Center | 12″/9″/6″ 3000W Tri-ring Power Boil |
| Element – Right Rear | 6″ 1200W (Melt) |
| Product Type | Cooktop |
APPEARANCE
| Frame Color / Material | Stainless Steel |
| Color Appearance | Stainless Steel on Black |
| Control Knobs | Stainless Steel Appearance |
WEIGHTS & DIMENSIONS
| Cooktop Size | 36.00 |
| Overall Height | 3 3/8 |
| Cabinet Width | 36.00 |
| Approximate Shipping Weight | 48.00 |
| Cutout Dimensions (Width x Depth) (In.) | 33.00 |
| Overall Width | 36 1/4 |
| Net Weight | 42.00 |
| Overall Depth | 21 1/8 |
POWER / RATINGS
| Recommended Circuit Breaker (Amps) at 240V | 40 |
| Max. Connected Load (kW) at 240V | 9.4 |
| Max. Current Draw (Amps) at 240V | 39.2 |
| Max. Connected Load (kW) at 208V | 7.1 |
| Recommended Circuit Breaker (Amps) at 208V | 40 |
| Max. Current Draw (Amps) at 208V | 34.1 |
WARRANTY
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
| Labor Warranty | Limited 1-year entire appliance |
CERTIFICATIONS
| Claims & Certifications | ADA Compliant UL CUL California Prop 65 |
