Description
FeaturesHot Surface Indicator LightA hot surface indicator light illuminates when the cooktop surface is still hot to the touch even after the heating element has been turned Drip BowlsHelps catch spills and wipe up
| UL | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY – WARNING: Cancer and Reproductive Harm – |
Details
| Fuel Type | Electric |
| Installs Over Built-In Oven | Yes |
| Power Outage Compatible | No |
| Cooktop Type | Standard |
| Cooktop Surface Color | White |
| Digital Display | No |
Element/Burner Details
| Cooktop Element Style | Coil |
| Cooktop Type | Standard |
| Left Front Element-Burner Power | 1,500W |
| Left Front Element-Burner Size | 6in. |
| Left Front Element-Burner Type | Coil |
| Left Rear Element-Burner Power | 2,350W |
| Left Rear Element-Burner Size | 8in. |
| Left Rear Element-Burner Type | Coil |
| Number of Cooking Element-Burners | 4 |
| Right Front Element-Burner Power | 2,350W |
| Right Front Element-Burner Size | 8in. |
| Right Rear Element-Burner Size | 6in. |
| Right Front Element-Burner Type | Coil |
| Right Rear Element-Burner Power | 1,500W |
| Right Rear Element-Burner Type | Coil |
Exterior Details
| Knob Color | Color Coordinated |
| Knob Type | Dishwasher-Safe Plastic |
Controls
| Control Location | Right Side |
| Control Type | Knobs |
| Cooktop Selections | Power On Indicator Light |
Dimensions
| Cutout Depth | 19-813/1000 in |
| Cutout Height | 4-3/4 in |
| Cutout Width | 28-313/1000 in |
| Cutout Width Max | 28-7/8 in |
| Depth | 21 in |
| Gross Weight | 32 lbs |
| Height | 3-1/4 in |
| Net Weight | 0 lbs |
| Width | 30 in |
Ventilation Details
| Downdraft Vent | No |
Cooktop Details
| Cooktop Surface Color | White |
| Cooktop Surface Material | Stainless Steel |
| Digital Display | No |
| Griddle Included | N/A |
| Heating Element On Indicator Light | Yes |
| Hot Surface Indicator Light | No |
| Combination Match with Oven | WOS11EM4 , WOS51EC0 , WOS51EC7 , WOS51ES4 , WOS72EC0 , WOS72EC7 , WOS92EC0 , WOS92EC7 , WOS97EC0 , WOS97ES0 , WOSA2EC0 |
| Cooktop Selections | Power On Indicator Light |
| Installs Over Built-In Oven | Yes |
Electrical Requirements
| Power Cord Included | No |
Documents
Owner’s ManualDownload (PDF 327.0KB)
Instruction SheetDownload (PDF 164.0KB)
Parts ListDownload (PDF 161.0KB)
WarrantyDownload (PDF 95.0KB)
Installation InstructionsDownload (PDF 349.0KB)
Dimension GuideDownload (PDF 101.0KB)
